Category:
Gear oil for manual transmissions and drive axis
Item number:
1223210
Oil type:
Mineral
Specifications:
Universal application, multi-purpose mixed pattern for machinery<br />Excellent impact and wear-EP<br />Very good oxidation and corrosion protection even in the presence of moisture<br />Very good mechanical stability<br />Excellent water resistance<br />Long service life and thus extended lubrication intervals possible<br />Very good resistance to aging<br />Good pumpability, even at low temperatures<br />
,
Universal use<br />Extreme shear stability<br />Excellent wear protection<br />Excellent corrosion protection<br />Very good mechanical and chemical stability<br />Very good aging resistant<br />Good pump output also at low temperatures<br />
Recommendations:
<p><b>RAVENOL Hydraulikoel TS 22 (HLP)</b> is for universally use in all hydraulic systems. </p>
<p><b>RAVENOL Hydraulikoel TS 22 (HLP)</b> is recommended in high performance hydraulic systems with high pressure pumps of all types, in sensitive control systems. </p>
<p><b>RAVENOL Hydraulikoel TS 22 (HLP)</b> is used for hydraulic systems in agriculture, to supply small gearboxes and for use in circulating systems. </p>
,
FORD M2C-9002 A
,
<p><b>RAVENOL Hydraulikoel TS 100 (HLP)</b></p>
<p>is for universally use in all hydraulic systems. </p>
<p><b>RAVENOL Hydraulikoel TS 100 (HLP)</b></p>
<p>is recommended in high performance hydraulic systems with high pressure pumps of all types, in sensitive control systems. </p>
<p><b>RAVENOL Hydraulikoel TS 100 (HLP)</b> is used for hydraulic systems in agriculture, to supply small gearboxes and for use in circulating systems. </p>
,
<p></p>
<p><b>RAVENOL Hydraulikoel TS AF 2</b></p>
<p> is for use as a hydraulic fluid in the metal industry, if zinc and ash-free hydraulic oil and the specification DIN 51 524, Part 2 is required. </p>
,
<p><b>RAVENOL Sperrdiff.-Getr.-Oel LS 90 GL-5 </b>was specially developed for use in differential with high requirements on differential with differential lock. </p>
,
<p><b>RAVENOL Hydraulikoel TSX 15 (HVLP)</b> is suitable for heavy loaded hydraulic machines of the industry, for earth moving machines and agricultural machines. Preferred use in case of great variations of the operation temperature. No use in case of silver and/or silver-coated components in the hydraulic machines. </p>
,
ZF TE-ML 07A
,
<p><b>RAVENOL DPS Fluid</b> is used in vehicles with 4WD Real Time, e.g. Honda CR-V, Honda Element, Honda Odyssey, Honda Fit, Honda Orthia and others. </p>
RAVENOL Getriebeoel EPX SAE 140 GL4/GL-5 is a lubricating oil for mechanical transmissions based on high quality base oils and additives that are a balanced combination of active ingredients. Special high-pressure (EP) agents and other additives offer excellent wear protection even under severe operating conditions.
Application note
RAVENOL Getriebeoel EPX SAE 140 GL4/GL-5 is designed for use in highly loaded, hypoid gears for hypoid gearbox, as well as for axle, transfer case, transmission gear, auxiliary gearboxes in vehicles and machinery and for use as an extreme pressure gear oil where this grade of lubricant is specified by the manufacturer.
Characteristics
- good adhesion and pressure resistant lubricating film
- excellent oxidation stability
- exceptional viscosity-temperature behavior
- a low pour point
- excellent protection against rust and corrosion
- enhanced wear-inhibiting effect
- a good foam-resistant composition
- compatible with all types of metals and sealing materials
Technical data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Aussehen/Farbe | braun | VISUELL | |
| Viskosität bei 100 °C | mm²/s | 26,0 | DIN 51562-1 |
| Viskosität bei 40 °C | mm²/s | 352,0 | DIN 51562-1 |
| Viskositätsindex VI | 97 | DIN ISO 2909 | |
| Brookfield Viskosität bei -12 °C | mPa*s | 55.000 | ASTM D2983 |
| Cu-Korrosion bei 121 °C | 1b | ASTM D130 | |
| Dichte bei 20 °C | kg/m³ | 894,0 | EN ISO 12185 |
| Flammpunkt | °C | 222 | DIN EN ISO 2592 |
| Pourpoint | °C | -21 | DIN ISO 3016 |
