RAVENOL AWD-TOR FLUID is a high quality full synthetic formulation based on polyalphaolefins (PAO) with a special additive and inhibition to ensure proper functioning of the gearbox.
RAVENOL AWD-TOR FLUID is a special transmission oil for transfer cases of four-wheel drive systems from Torsen type of VW and AUDI. To improve the operating characteristics of intermittent loads, 4% of a particular friction modifier is used in the recipe RAVENOL AWD-TOR FLUID guarantees low wear and, thanks to its excellent properties, ensures a long service life of the gearbox.
Application note
RAVENOL AWD-TOR FLUID is suitable for use in transfer cases of Torsen type four-wheel drive systems from VW, AUDI and other vehicle manufacturers.
RAVENOL AWD-TOR FLUID is excellently suited for use in normal road traffic as well as in motorsports.Observe manufacturer's instructions.
Characteristics
- An addition of 4% of a special friction modifier
- Excellent flowability at low temperatures
- Low wear
- High, stable viscosity index
- Reliable protection against wear, corrosion and foaming
- Excellent viscosity-temperature behavior
- Neutral behavior towards sealing materials
Technical data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Aussehen/Farbe | braun | VISUELL | |
| Seq. I bei 24 °C | ml/ml | 0/0 | ASTM D892 |
| Seq. II bei 93,5 °C | ml/ml | 0/0 | ASTM D892 |
| Seq. III bei 24 °C nach 93,5 °C | ml/ml | 0/0 | ASTM D892 |
| Viskosität bei 100 °C | mm²/s | 16,7 | DIN 51562-1 |
| Viskosität bei 40 °C | mm²/s | 107,9 | DIN 51562-1 |
| Viskositätsindex VI | 168 | DIN ISO 2909 | |
| VKA Vier Kugel Test (Verschleiß) | mm | 0,71 | DIN 51350-3 |
| VKA Vier Kugel-Test (Hochdruck) | N | 3600 / 3800 | DIN 51350-3 |
| Brookfield Viskosität bei -40 °C | mPa*s | 48.700 | ASTM D2983 |
| Cu-Korrosion bei 150 °C | 1a | ASTM D130 | |
| Dichte bei 20 °C | kg/m³ | 864,0 | EN ISO 12185 |
| Pourpoint | °C | -54 | DIN ISO 3016 |
