RAVENOL ATF THS Truck HD Synthetic is a very high-quality synthetic transmission fluid with special additives and is particularly suitable for Allison automatic transmissions.
RAVENOL ATF THS Truck HD Synthetic was developed for year-round use under the toughest conditions and meets the requirements of many automatic transmissions in commercial vehicles and busses.
RAVENOL ATF THS Truck HD Synthetic improves friction and wear and leads to reduced noise and a smoother shifting process.
Application note
RAVENOL ATF THS Truck HD Synthetic was developed for use in transmissions installed in commercial vehicles, especially for use in Allison truck and bus automatic transmissions.
RAVENOL ATF THS Truck HD Synthetic is particularly suitable if the specifications TES 668, TES 468, TES 389 or TES 295 are recommended.
RAVENOL ATF THS Truck HD Synthetic is to be used in accordance with the manufacturer's instructions.
Characteristics
- Very good friction resistance
- Excellent low temperature properties
- A thermally extraordinarily high load capacity
- Neutral behavior towards sealing materials
- Oxidation stable
- High shear stability
- Low maintenance costs due to extended oil change intervals
- Prevents deposits on transmissions
Technical data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Aussehen/Farbe | rot | VISUELL | |
| Viskosität bei 100 °C | mm²/s | 7,0 | DIN 51562-1 |
| Viskosität bei 40 °C | mm²/s | 34,5 | DIN 51562-1 |
| Viskosität bei -40 °C | mPa*s | 10.300 | ASTM D2983 |
| Viskositätsindex VI | 173 | DIN ISO 2909 | |
| Dichte bei 20 °C | kg/m³ | 843,0 | EN ISO 12185 |
| Flammpunkt | °C | 228 | DIN EN ISO 2592 |
| Noack Verdampfungstest | %m | 2,1 | ASTM D5800 |
| Pourpoint | °C | -45 | DIN ISO 3016 |
