RAVENOL ATF MERCON® LV Fluid is synthetic ATF Automatic Transmission Fluid, which was specially developed for automatic transmission of Ford. The special formulation ensures a long service life of the lubricant and provides excellent protection against abrasion and wear.
RAVENOL ATF MERCON® LV Fluid meets the relevant requirements of the gear oil specifications from Ford.
Application note
RAVENOL ATF MERCON® LV Fluid is used when the automatic transmission oil specification MERCON® LV is required.
RAVENOL ATF MERCON® LV Fluid meets relevant requirements of the gear oil specifications from Ford for automatic transmission TorqShift 6R140 (Powerstroke from 2010), TorqShift 5R110 (Ford Super Duty 2003-2009), 4R75W / E (from 2009), 6R80, 4F27E, 6F50N / 55N (from 2010), and 6F35N HF35 hybrid.
Characteristics
- Very good lubricity also by low temperatures
- High, stable viscosity index
- Very good oxidation stability
- Excellent wear, corrosion and foaming protection
- Excellent friction constant
- High thermal and oxidative stability
- Excellent cooling capacity
- Improved shear stability
Technical data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Aussehen/Farbe | rot | VISUELL | |
| Schaumtest (Seq. I, II, III) | min. | 0/0, 0/0, 0/0 | ASTM D892 |
| Viskosität bei 100 °C | mm²/s | 5,9 | DIN 51562-1 |
| Viskosität bei 40 °C | mm²/s | 29,2 | DIN 51562-1 |
| Viskositätsindex VI | 150 | DIN ISO 2909 | |
| Brookfield Viskosität bei -40 °C | mPa*s | 9.010 | ASTM D2983 |
| Cu-Korrosion bei 121 °C | 1b | ASTM D130 | |
| Dichte bei 20 °C | kg/m³ | 840,0 | EN ISO 12185 |
| Flammpunkt | °C | 224 | DIN EN ISO 2592 |
| Pourpoint | °C | -51 | DIN ISO 3016 |
