Category:
Gear oil for automatic transmissions
Item number:
1211103
Oil type:
Synthetic
Approvals:
Allison C4-32652009 (ATF II E)
,
MB Freigabe 236.8
,
Voith H55.6336.3x Extended Drain (G1363)
Recommendations:
Caterpillar TO-2
,
DTFR 13C150 (MB 236.8)
,
MAN 339 V2
,
MAN 339 Z2
,
MB 236.5
,
ZF TE-ML 04D
,
ZF TE-ML 09X
,
ZF TE-ML 14B
,
ZF TE-ML 16L
RAVENOL ATF Dexron II E is high performance synthetic automatic transmission oil ATF for use in torque converter transmission and power shift transmission of vehicles with specification GM Dexron II E, Ford Mercon and Allison C-4.
Application note
RAVENOL ATF Dexron II E is developed for use in automatic transmission and torque converter transmission and power shift transmission with required specification.
RAVENOL ATF Dexron II E is recommended if ATF Type Dexron II E is to be used according to manufacturer’s specification.
Characteristics
- reliable protection against wear, sludge, adhesion and corrosion
- a very shear stable viscosity-temperature behaviour
- can be used both at very low and very high temperatures
- an extremely high thermal load
- no foaming, even under the heaviest loads
- compatibility with sealing materials
Technical data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Aussehen/Farbe | rot | VISUELL | |
| TBN | mg KOH/g | 1,7 | ASTM D2896 |
| Viskosität bei 100 °C | mm²/s | 7,5 | DIN 51562-1 |
| Viskosität bei 40 °C | mm²/s | 32,0 | DIN 51562-1 |
| Viskosität bei -40 °C | mPa*s | 8.300 | ASTM D2983 |
| Viskositätsindex VI | 191 | DIN ISO 2909 | |
| Dichte bei 20 °C | kg/m³ | 834,0 | EN ISO 12185 |
| Flammpunkt | °C | 226 | DIN EN ISO 2592 |
| Pourpoint | °C | -57 | DIN ISO 3016 |
