RAVENOL LKW FETT BLAU

Category: Grease

Item number: 1340117

Application: Truck , Agricultural machinery

Oil type: Mineral

Specifications: DIN 51502: KP2N-30 , ISO 6743-9: ISO-L-XCDIB2 , VOLVO STD „Lubricating grease 97720“

Approvals: MAN 283 Li-P2 , MB Freigabe 267.0

Recommendations: DTFR 33B120 (MB 267.0) , VW/Audi G 052 180 A1

RAVENOL LKW FETT BLAU is a lithium saponified multipurpose grease on mineral basis with oxidation and corrosion protective additives.

Because of its special additivation RAVENOL LKW FETT BLAU has an excellent pressure absorption capacity, excellent corrosion protection characteristics and a superior mechanical stability.

Application note

RAVENOL LKW FETT BLAU is used for the lubrication of high loaded friction and antifriction bearings of trucks and construction machines even under the influence of humidity, vibration and shock loading. Functional range from - 30°C up + 125°C (maximum + 140°C). NLGI class 2. Extended lubrication intervals.

Characteristics

Extreme shear stability
Excellent corrosion protection
Very good mechanical and chemical stability
Very good aging resistance
Good pump output also at low temperatures

Technical data

Property	Unit	Data	Audit
Aussehen/Farbe		blau	VISUELL
Tropfpunkt	°C	220	DIN ISO 2176
Verdicker		Lithium-Komplexseifen	DIN 51757
VKA Schweißkraft	N	2200-2400	DIN 51350-4
Walk-Penetration 60 strokes	mm/10/25°C	265-295	ISO 2137
Wasserbeständigkeit (3h/90 °C)	°C	1-90	DIN 51807-1
Einsatz-Temperatur-Bereich	°C	-30 / +140	DIN 51825
Kinematische Viskosität (Basisöl) bei 40 °C	mm²/s	220	DIN 51562-1
Korrosion (SKF Emcor dest. Wasser)	Korr. Grad	0	DIN 51802
Kupferkorrosion (24h/120 °C)		1	DIN 51811
max. kurzfristige Gebrauchstemperatur	°C	220	DIN 51757
NLGI-Klasse		2	DIN 51818
Produkt-Klassifikation		KP2N-30	DIN 51502
